Description
A 24V DC high-flow, high-pressure diaphragm washdown pump from Jabsco Xylem. This HotShot HD6 heavy duty model features a wide diameter motor (compared to standard non-HD models) with a powder-coated shell, cast aluminium endbells and lower housing to improve pressure capability and life.
The pump has vibration-dampening feet for quiet operation and an integrated, sealed pressure switch for on-demand operation. It has a dry self-priming capability of 2.1 meters (7ft) and can run dry without damage.
The Jabsco Xylem HotShot HD6 is supplied with quick connect straight hose barb and GHT fittings, a 90° 20 mesh quick connect strainer and trigger nozzle and quick connect hose adapters.
– Voltage: 24V DC
– Open flow GPM (LPM): 6 (23)
– Shut-off pressure PSI (BAR): 70 (4.8)
– Max. current AMPS: 9.4
– Recommended fuse size: 15
– Dimensions: 10.2″ in length, 5.1″ in width, 4.7″ in height / 259(L) x 129(W) x 119(H)mm
| Approvals | ISO 8846 Ignition Protected, C.E Certified, RCM compliant |
| Cut In Pressure | 51 PSI |
| Cut Out Pressure | 70 PSI / 4.8 Bar |
| Flow Rate | 23 LPM (6 US GPM) |
| Fuse | 15A (not included) |
| Height | 119mm |
| Size | Leads: 12″ (305mm), 14 AWG (2.5mm^2) |
| Supplied With | Inline Strainer (40 mesh) & Quick Connect Fittings- no hosecoil |
| Temperature Range | Ambient & Fluid: 0°C to 60°C (32°F ‐ 140°F) |
| Voltage | 24V DC |
| Weight | 8.06kg |
| Width | 129mm |
| Brand | Jabsco |
| Model | P602J-219N-3A |
| Pressure Rating | Operating: 70 PSI (3.4 bar) maximum, Inlet: 30 PSI (2.1 bar) maximum |
| Replaces | JAB-82605-0094 |
| Self Primes up to | Up to 7ft (2.1m) dry prime |
| Inlet Outlet | Fittings for 13mm (1/2″) ID hose and US Garden Hose Thread |
| Amps | 9 Amps at 70 PSI (4.8 BAR) |
| Depth | 260mm |
Jabsco Hotshot Series Brochure enTechnical Data Sheet Jabsco Xylem Hotshot HD6 P602J 219N 3A
