Description
- Horizontal windlasses
- Base in anodized aluminum in hard oxide
- With and without drum
- Integrated sensor and magnet for chain counter
- Manual Free-Fall system
- IP66 watertight motor
Easy Installation the vertical motor allows for extremely simple and quick installation.
| Eagle | 300 W | 5 – 7 m | 16 – 23 ft |
| Eagle | 500 W | 6 – 9 m | 20 – 29 ft |
The indication may vary according to the boat type and the anchor-rode type.
| Gypsy and Drum | Ø 90 mm / 3″ 35/64 |
| GYPSY | 6 mm | |
| CHAIN | 6 mm | 6 mm |
| DIN 766 | ISO |
Supplied accessories standard
| Contactor units | Nylon handle | |||||||
|
Optional accessories
|
Hydraulic magnetic |
UP/DOWN control board |
Foot |
handheld |
Chain |
Radio remote |
| Standard version | E1 500 / 500 D |
| Motor power | 500 W |
| Motor supply voltage | 12 V |
| Maximum pull | 630 Kg / 1389 lb |
| Maximum working load | 250 Kg / 551 lb |
| Working load | 80 Kg / 176 lb |
| Current absorbtion @ working load (1) | 90 A |
| Maximum chain speed (2) | 22,2 m/min / 72.8 ft/min |
| Maximum chain speed @ working load (2) | 16,5 m/min / 53.1 ft/min |
| Weight – Eagle – [without drum] | 8,0 Kg / 17.6 lb |
| Weight – Eagle D – [with drum] | 9,3 Kg / 20.5 lb |
| 1) | After an initial period of use |
| 2) | Measurements taken with a gypsy for a 6 mm chain |
Dimensions
E1 500/500D
Deck thickness:
20÷40 mm (25/32″÷1″ 9/16)
On request, shaft and studs can be supplied for greater deck thicknesses.
Dimensions in mm (inch)
Supplied accessories standard
| Contactor units | Nylon handle | |||||||
|
Optional accessories
|
Hydraulic magnetic |
UP/DOWN control board |
Foot |
handheld |
Chain |
Radio remote |
