Description
Manhattan kitchen mixer tap with a brushed stainless steel finish and curved swivel spout.
Performance:
– Minimum Operating Pressure: 0.5 bar
– Maximum Operating Pressure: 5 bar
Flow Rates:
– At 0.2 bar: 3.8 l/min
– At 0.5 bar: 5.4 l/min
– At 1 bar: 7.2 l/min
– At 2 bar: 10.8 l/min
– At 3 bar: 12.4 l/min
Connections and Installation:
– Flexible Tails Included: Yes
– Number of Tap Holes Required: 1
– Handle Type: Lever
– Swivel Spout: Yes
– Inlet Connection: 1/2″ M10
– Tap Hole Diameter: 35mm
– Tap Type: Mono Mixer
– Valve / Cartridge Type: Single Lever Cartridge 35mm
– Includes waste: No
| Approvals | WRAS Approved |
| Finish | Stainless Steel |
| Flow Rate | At 0.2 bar: 3.8 l/min, At 0.5 bar: 5.4 l/min, At 1 bar: 7.2 l/min, At 2 bar: 10.8 l/min, At 3 bar: 12.4 l/min |
| Height | 367mm |
| Inlet Connection | 1/2” M10 |
| Material | Stainless Steel Alloy 304 |
| Weight | 1.4kg |
| Width | 52.5mm |
| Brand | AG |
| Diameter | Tap hole: 35mm |
| Model | Manhatattan |
| Operating Pressure | Minimum: 0.5 bar, Maximum: 5 bar |
Data Sheet KT42 minEasy Fit Fixture Instructions minInstallation Guide minWRAS Certificate KT42 min
Manufacturer Part Number: KT42
